  • UN4S-20 7K BAUER UNICUS 4S | UN4S-20 7K | Three Phase | 7000PSI

UN4S-20 7K BAUER UNICUS 4S | UN4S-20 7K | Three Phase | 7000PSI

(0)No Reviews yet
CALL FOR PRICE OR REQUEST QUOTE
SKU: UN4S-20 7K

Benefits include:

  • The integrated 7-inch HMI touch screen allows operators to control the entire system from a central location with full visual interface of all system functions.
  • The optional BAUER Gas-Tek™ gas monitoring system utilizes state-of-the-art gas sensor technology with real-time assessment of breathing air quality to assure safety. Trace elements of CO and other harmful gases in excess of preset limits will force the compressor to shut off and display an alarm on the HMI touch screen. The HMI will also automatically prompt a quarterly system calibration in accordance with NFPA guidelines.
  • The optional RFID Reader (Data-Logging Interface) automatically reads and records data from the RFID equipped SCBA cylinders. Simply set the cylinder in one of three (3) fill positions and the scanner antenna will automatically provide the date/location/pressure/person of the last fill along with serial number and the bottle’s total number of fills. NFPA 1989 data collection made easy.

BAUER UNICUS 4s; 7000PSI; Three Phase; 20HP; 11KW

STANDARD SCOPE OF SUPPLY

  • BAUER breathing air purification system with SECURUS
  • BAUER PLC based controller with 7” color HMI touchscreen display
  • NEMA 4 rated electrical enclosure with UL® listed control panel
  • Compressor low oil pressure and high temperature safety shutdowns
  • Emergency stop push button
  • Hinged cascade fill control panel with Lexan laminate air flow/fill schematic
  • Audible alarm on safety shutdowns
  • Inlet filter maintenance indicator
  • Automatic condensate drain system with non-corrosive condensate reservoir and integrated float sensor and automatic “Full” indication
  • and compressor shutdown
  • Two (2) ASME code stamped air cylinders installed in an integral rack designed to hold four cylinders
  • Sound attenuating enclosure with slam-action latches and lift-off type hinges
  • NFPA 1901 2016 edition compliant 3 position containment fill station accommodates SCBA or SCUBA cylinders up to 31” overall length
